Affichage de multi-angle
703F Bright Silver (China IV / 21-inch crash bar + 3-case brackets / BRM / ETC)
➤
703F Piano Black Grey (China IV / 21-inch crash bar + 3-case brackets / BRM / ETC)
➤
Paramètres techniques
Moto complète
length (mm)2355
Width (mm)960
Height (mm)1395
Wheel base (mm)1565
Loading capacity (kg)217
Gross mass (kg)237
Minimum ground clearance (mm)205
Gasoline tank volume (L)22
Seat height (mm)845
Système d'alimentation
The bodyAlliage d‘aluminium
Cylinder number三缸
Camshaft systemDouble arbre à cames en tête
Bore X Stoke (mm)70 x 60.6
Cooling systemRefroidissement par eau
Fuel95 ou plus
Compression ratio13 : 1
Displacement(ml)699
Fuel supply methodPulvérisation électrique intelligente
Electrical fuel injection system马瑞利
Throttle configurationETC
Ignition systemAllumage électronique
Transmission systemCha?ne d’étanchéité
Idling speed (r/min)1350±100
Maximum power (kW/rpm)71.5/10000
Maximum torque (N.m/rpm)76/7500
Transmission常啮式六段变速
GearFichier international
ClutchMultiples humide
Economical consumption of fuel (L/km)5/100
Système de suspension
Frame system铝合金双翼梁车架
Tire structurePneu semi-thermofusible
Front rim sizeMT:2.15×21
Rear rim sizeMT:4.25×18
Front tire specification90/90-R21
Rear tire specification150/70-R18
Front brake specificationfrein à disque
Rear brake specificationfrein à disque
Headlamp/tail light/steering lampLED
Brake systemSistema ABS de doble canal
