Affichage de multi-angle
368G Black low seat (Chinese IV)
➤
368G Mech Grey Low Seat Version (China IV / ETC)
➤
368G Green Low Seat Version (China IV / ETC)
➤
368G Matte Brown Low Seat Version (China IV / ETC)
➤
Paramètres techniques
Moto complète
length (mm)2230
Width (mm)925
Height (mm)1370
Wheel base (mm)1560
Loading capacity (kg)180
Gross mass (kg)192
Minimum ground clearance (mm)180(高版) 155(矮版)
Gasoline tank volume (L)17.5
Seat height (mm)795(高版) 770(矮版)
Système d'alimentation
The bodyAlliage d‘aluminium
Cylinder numberMonocylindre
Camshaft systemArbre à camesplafonnier simple(SOHC)
Bore X Stoke (mm)79 x 75
Cooling systemRefroidissement par eau
Fuel95 ou plus
Compression ratio11.8 : 1
Displacement(ml)368
Fuel supply methodPulvérisation électrique intelligente
Electrical fuel injection systemBOSCH
Throttle configurationETC
Ignition systemAllumage électronique
Idling speed (r/min)1600 ± 100
Maximum power (kW/rpm)28.5/7500
Maximum torque (N.m/rpm)40/6000
Transmission自动无级变速
Economical consumption of fuel (L/km)3.5/100
Système de suspension
Frame systemCadre en acier
Tire structurePneu semi-thermofusible
Front rim sizeMT: 3.0×17
Rear rim sizeMT: 4.25×14
Front tire specification110/70-17
Rear tire specification150/70-14
Front brake specificationfrein à disque
Rear brake specificationfrein à disque
Headlamp/tail light/steering lampLED
Brake systemSistema ABS de doble canal
